Quick Release Tuff Curb XLP Lane Separator
1 of 4 (Enlarge)

Quick Release Tuff Curb XLP Lane Separator

Product ID: RPMRITXLP(XX)Q(R)
Price: $95.87
Quantity:
 Add to cart Checkout
  • Description
  • Video
  • Literature

NOTE: The most popular markers are available online. To order other configurations, please call Customer Service at 1-800-367-1492.


Quick Release Tuff Curb XLP Lane Separator

Use the Quick Release Tuff Curb XLP Lane Separator knowing that it will endure high speed and high impact applications.

  • PRODUCT ID: RPMRITXLP(XX)Q(R)
  • Body Colors (X): (WH) White | (YE) Yellow
  • Coupler: Quick-Release
  • Size: Curb - 40" x 8" x 2"
  • Reflective Marker Options for White Body (R): (WN) White - 1-Way | (WW) White - 2-Way | (RW) Red/White 2-Way
  • Reflective Marker Options for Yellow Body (R): (YY) Yellow/Yellow - 2-Way
  • Highly visible and resistant to UV damage and fading.
  • TUFF Curb XLP is a extreme low profile, high performance road lane separator curb system designed to endure damaging high speed, high impact applications.
  • Material: Made from solid colored, UV resistant, high density polyethylene (HDPE).
  • Weight: 6 lbs. Despite its light weight, the unique XLP undercarriage rib design can bear 20,000 lbs of static pressure - double the federal single axle vehicle maximum for a single wheel.
  • The one piece design eliminates the need for end caps and by installing the sections 2-3" apart water flows through unimpeded.
  • MASH 2009: XLP was tested and is federally accepted to 2009 MASH standards.
  • Compatibility: Tuff Curb XLP road lane divider is compatible with the premium line of Quick Release Markers and Delineators.
  • Installation: Install with 2-3 anchors or epoxy, sold separately.
  • Installation Notes on the Challenge of Anchoring to Asphalt: Asphalt is gravel held together with oily pitch ("Bitumen"). Unlike concrete, asphalt will yield to forces applied for extended amount of time. For this reason, the common expansion anchors (which are used on concrete) can not be used for fastening to asphalt. Any expansion anchor installed in asphalt will loosen and fail within days.
