Reserved Parking (Handicap Symbol) with Optional Arrow Sign
Use the Reserved Parking (Handicap Symbol) with Optional Arrow Sign to let people know that this spot is reserved for handicapped only.
-
PRODUCT ID: S(XXXX)R78(A)(X)A
-
Size (XXXX): (1218) 12" x 18" for use on Single/Multi-Lane Roads
- Optional Arrow (A): (L) Left | (R) Right | (D) Double
Reflective Sheeting (X): (H) High Intensity Prismatic
-
Substrate: .080" Aluminum
-
MUTCD Sign Designation: R7-8 No Arrow | R7-8L Left Arrow | R7-8R Right | R7-8D Double Arrow
- Learn about Digitally Printed Traffic Signs
Federal Rules Impact on Private Property
