Semi Gloss Powder Painted 5.5" Crosspiece Sign Bracket | Clarksdale System
Standard brackets are designed for street name sign blades up to 6" tall; typically used in neighborhoods with speed limits of 25 MPH or under.
Go to Step 6 to a Choose Street Name Sign Blades for the Clarksdale System
-
PRODUCT ID: OSIZ1CRP990(F)BK
-
Slot Size: 5.5"
-
For Blade Type: (F) Flat
-
Material: Aluminum
-
Color/Finish: Black Semi-Gloss Powder Paint
- More Powder Paint Colors Available by Custom Order. Call 1-800-367-1492 for a quote on Custom Orders. Choose custom order colors from the CPC Standard Powder Paint Color Chart.
download pdf | view digital edition
-
Hardware: This bracket comes individually packaged in a plastic bag with the hardware pre-inserted in bracket to attach bracket to sign. Vandal resistant hardware upgrades are available.
-
Compatibility:This universal bracket is designed for use with 45, 90 and 180 degree standard brackets.
-
MUTCD Guidance: Recommended for street name flat sign blades no more than 6" tall. Not recommended for 9" tall or larger street name signs. Jumbo brackets are available for larger signs.
-
Installation Notes: Brackets must be installed with appropriate hand tools. Brackets should be hand tightened to 3 Foot Pounds of Torque. This is sufficient for the set screw to bite into the aluminum sign and prevent it from coming out of the bracket. Over-tightening causes the bracket to flare and ultimately break as well as embed itself into the aluminum sign. Power tools such as drills and impacts should NOT be used. Power tools cause over tightening, which in turn, causes bracket failure. Returns or exchanges are not available if power tools have been used.
-
NOTE: Available in box quantities by calling customer service at 1-800-367-1492.
